Lamella Clarifier (Inclined Plate Settler) for Water & Wastewater Treatment

Lamella Clarifier

Inclined Plate Sedimentation Tankfor Wastewater Treatment

Lamella Clarifier for Efficient Water & Wastewater Treatment

A Lamella Clarifier, also known as an Inclined Plate Settler or Inclined Plate Clarifier, is a high-efficiency sedimentation system designed for solid-liquid separation in water treatment and wastewater treatment applications. By incorporating multiple inclined plates inside the clarifier, the system significantly increases the effective settling area within a compact footprint, allowing suspended solids to settle much faster than in conventional settling tanks.

How Does a Lamella Clarifier Work?

The Lamella Clarifier operates on the principle of gravity sedimentation. Wastewater enters the inlet chamber and is evenly distributed across a series of inclined plates. As the water flows upward between the plates, suspended particles settle onto the plate surfaces and slide downward into the sludge hopper under gravity. The clarified water continues to flow upward and exits through the overflow weir, while the collected sludge is discharged from the bottom of the unit. This continuous process provides stable and efficient solid-liquid separation with minimal energy consumption.

Why Choose a Lamella Clarifier Instead of a Conventional Settling Tank?

Compared with traditional sedimentation basins, an Inclined Plate Settler offers a much larger effective settling area in the same installation space. This compact design improves clarification efficiency, reduces the required footprint, shortens hydraulic retention time, and lowers civil construction costs. The system also delivers more consistent effluent quality, making it an ideal solution for modern water treatment and wastewater treatment plants where space, efficiency, and operating costs are critical.

Typical Applications

The Lamella Clarifier is widely used in both municipal and industrial water treatment processes. It is suitable for drinking water treatment, municipal wastewater treatment, and a wide range of industrial applications, including food and beverage processing, dairy, textile, paper mills, mining, chemical manufacturing, electroplating, metal finishing, power generation, and oil & gas industries. It is commonly installed as a primary clarification unit, a coagulation-flocculation clarification system, or a pretreatment stage before filtration, DAF, biological treatment, or membrane systems.

After-sales Service

（√）InstallationVideo Guidance
Video guidance helpscustomers install themachine step by step.

（√）Operation Manual
Clear English manualsupports daily operationand maintenance.

（√） Online TechnicalSupport
Our team providesonline support foroperation andtroubleshooting.

（√） Spare Parts Supply
Common spare partscan be supplied quicklywhen needed.

（√） Machine Debugging Before Shipment
Each machine is testedand adjusted beforedelivery.

（√） Remote Troubleshooting Support
Remote assistance helpssolve technical problemsefficiently.
